| ISP Process | 28nm |
|---|---|
| Product Structure | PoP |
| CPU | CortexA7-Quad 650MHz |
| Package size | 15㎜ x 15㎜, 0.5㎜ pitch |
| SDRAM type | LPDDR-3 |
| Image Processing rate | Max 1.2Gpixel/sec |
| Max Pixel Size | No Limitation |
| Sensor I/F | MIPI Rx(4lane) 2.5Gbps x 4ch |
| S-LVDS(16lane/4clk) 1.0Gbps | |
| SLVS-EC(8lane) 2.3Gbps x 1ch | |
| Host I/F | PCI-e, USB3.0, 1Gbit Ethernet |
| LCD I/F | MIPI-DSI/16bit Parallel |
| TV I/F | HDMI 2.0 |
| Video Codec | H.264 4K p60/HEVC 4K p60 |
| Chroma NR | ○(Hardware) |
| Bayer NR(ELF) | ○(Hardware) |
| Lens Distortion Correction | ○(Hardware) |
| Face Detection | ○(Hardware Assist) |
| Smile/Blink Detection | ○(Hardware Assist) |
| High Dynamic Range(HDR) | ○(Hardware) |
| 动画抖动校正 (EIS) | ○(Hardware) |
| Defect Pixel Correction | ○(Hardware) |
| Color Aberration | ○(Hardware) |
| 3DNR | ○(Hardware) |
