| ISP Process | · 65nm CMOS Technology |
|---|---|
| Package Size | · Ball Pitch 0.5mm |
| · Body size 13mm x 13mm | |
| CPU | · ARM946E-S 288MHz x2 |
| Movie Codec | · H.264 1080/p30, 720/p30 |
| Image Processing rate | · 216Mpix/sec |
| Max Image Size | · 5.4K Pixel(Horizontal) |
| Sensor Interface | · Parallel：12bit 1ch |
| · Serial：sub-LVDS 8Lane, MIPI 4Lane | |
| Host Interface | · UART/CSIO 5ch, USB2.0 High-Speed |
| LCD Interface | · 8bit and 24bit |
| TV Interface | · Composite(NTSC,PAL) |
| · HDMI(need Ext Chip) | |
| Card Interface | · NandFlash, SDCard 2ch |
| Continuous Shooting | · 14M/7fps |
| Face Detection | · Support(Hardware Assist) |
| Distortion Correction | · Support(Hardware) |
| Video Stabilization | · Support(Hardware) |
| Still Stabilization | · Support(Hardware) |
