| SMD |
SMD |
| 形状 |
纵型表面贴装 |
| Polarity type |
极性 |
| 额定电压 (V) |
35 |
| 静电容量 (micro F) |
47 |
| 静电容量容差 (%) |
-20 to 20 |
| Tangent of loss angle (max.) |
0.16 |
| Leakage current (max.) (micro A) |
16.4 |
| 类别温度范围 (Cel) |
-40 to 125 |
| 主体直径 (mm) |
6.3 |
| 主体长度 (mm) |
7.7 |
| Lead (terminal) pitch (mm) |
- |
| Rated ripple current-1 (freq.) (Hz) |
1000000 |
| 额定纹波电流值-1 (mA) |
197 |
| Rated ripple current-1 (unit) |
mA r.m.s. (root mean square) |
| Impedance-1 (frequency) (Hz) |
- |
| Impedance-1 (max. value) (m Ohm) |
- |
| E.S.R.-2 (freq.) (Hz) |
- |
| E.S.R.-2 (max. value) (m Ohm) |
- |
| 耐久性(小时) (h) |
2000 |
| 加工及包装特点 |
Embossed carrier taping (reel packing) |
| 外观 |
Sheathless (metal case) |
| Quantity (min. packaging unit) (PCS.) |
900 |
| Weight (Typ.) (g) |
0.44 |
