| SMD |
SMD |
| 形状 |
纵型表面贴装 |
| Polarity type |
极性 |
| 额定电压 (V) |
10 |
| 静电容量 (micro F) |
680 |
| 静电容量容差 (%) |
-20 to 20 |
| Tangent of loss angle (max.) |
0.19 |
| Leakage current (max.) (micro A) |
68 |
| 类别温度范围 (Cel) |
-55 to 105 |
| 主体直径 (mm) |
8 |
| 主体长度 (mm) |
10.2 |
| Lead (terminal) pitch (mm) |
- |
| Rated ripple current-1 (freq.) (Hz) |
100000 |
| 额定纹波电流值-1 (mA) |
600 |
| Rated ripple current-1 (unit) |
mA r.m.s. (root mean square) |
| Impedance-1 (frequency) (Hz) |
100000 |
| Impedance-1 (max. value) (m Ohm) |
160 |
| E.S.R.-2 (freq.) (Hz) |
- |
| E.S.R.-2 (max. value) (m Ohm) |
- |
| 耐久性(小时) (h) |
5000 |
| 加工及包装特点 |
Embossed carrier taping (reel packing) |
| 外观 |
Sheathless (metal case) |
| Quantity (min. packaging unit) (PCS.) |
500 |
| Weight (Typ.) (g) |
0.88 |
