| Product Lifecycle Stage |
mass production |
| Applications |
Invertor motor control |
| ROM Size (KB) |
64 |
| ROM Type |
Mask ROM |
| RAM Size (KB) |
4 |
| Pin Count |
44 |
| Max Operating Frequency (MHz) |
60 |
| 8-bit Timer (ch) |
4 |
| 16-bit Timer (ch) |
2 |
| PWM (ch) |
2 |
| Serial I/F [Clock Synchronous] (ch) |
1 |
| Serial I/F [UART] (ch) |
1 |
| Serial I/F [I2C] (ch) |
- |
| Serial I/F [LIN] (ch) |
- |
| Serial I/F [CAN] (ch) |
- |
| Serial I/F [Remarks] |
Synchronous/UART x1 |
| USB Host (ch) |
- |
| DMA (ch) |
- |
| ADC [10bit] (ch) |
8 |
| ADC [12bit] (ch) |
- |
| ADC [Remarks] |
10bit x 2units |
| DAC [8bit] (ch) |
- |
| DAC [10bit] (ch) |
- |
| DAC [12bit] (ch) |
- |
| 3-Phase PWM Output Function (set) |
1 |
| Op amp |
- |
| Min Instruction Exec. Time / Voltage (ns) / (V) |
16.7 / 3.6 to 5.5 |
| Max Operating Voltage (V) |
5.5 |
| Min Operating Voltage (V) |
3.6 |
| Number of I/O Ports (ch) |
29 |
| Interrupt Sources (ch) |
28 |
| External Interrupt (ch) |
8 |
| External Bus Expansion |
- |
| High Speed On Chip Oscillator Frequency (MHz) |
- |
| Low Speed On Chip Oscillator Frequency (kHz) |
- |
| Power On Reset |
Yes |
| Low Voltage Detection |
- |
| Watch Dog Timer (ch) |
1 |
| Package |
QFP044-P-1010 |
| RoHS compliant *1 |
RoHS compliant (Please refer to the Related Information.) |
| REACH compliant *2 |
SVHC non-inclusion (Please refer to the Related Information.) |
