主要特点
- Pretty low leakage current (<1μA) at working voltage of 2.5V
- 3.5pF ultra low parasitic capacitance for each line pair
- Good capacitance uniformity in the range of 0V to 2.5V
- Lower trigger voltage (<4V) to response earlier under EOS events
- Ultra lower clamping voltage to protect ICs well
- Tiny package：DFN3020-10L
- Flow through PCB layout supportive
- Including GND pin for better ESD protection
概述
CS2204-25 is a low-capacitance Transient Voltage Suppressor (TVS) array designed to provide electrostatic discharge (ESD) protection for high-speed data interfaces. With typical capacitance of 3.8pF only, CS2204-25 is designed to protect parasitic-sensitive systems against over-voltage and over-current transient events. It complies with IEC 61000-4-2 (ESD) (±30kV air, ±30kV contact discharge), IEC 61000-4-4 (electrical fast transient - EFT) (40A, 5/50 ns), IEC 61000-4-5 (Surge) (40A, 8/20μs), very fast charged device model (CDM) ESD and cable discharge event (CDE), etc.
CS2204-25 is in a DFN3.0´2.0-10L package. Each CS2204-25 device can protect two high-speed line pairs. The “flow-thru” design minimizes trace inductance and reduces voltage overshoot associated with ESD events. The combined features of low capacitance and high ESD robustness make CS2204-25 ideal for high-speed data port and high-frequency line (e.g., Gigabit Ethernet Ports) applications. The low clamping voltage of the CS2204-25 guarantees a minimum stress on the protected IC.
Applications
- xDSL
- Wireless systems
- Ethernet 10/100/1000M
- Networks
